Description
SSR-PM is an industrial transmitter universal particle concentration, measured using laser light scattering principle, the unique data acquisition technology dual sieved particles obtained number of particles per unit volume equivalent particle diameter,.It can be used for monitoring the concentration of PM10 or PM2.5 need a place outdoor weather.
Colorlight SSR-PM Air quality (PM2.5/PM10) Transmitter Detector Features:
·Range: 0-6000ug/m3, the resolution: 1ug/m3;
·PM2.5, PM10 simultaneous output;
·Unique dual automatic data acquisition and calibration techniques, consistency of up to ±10%;
·The use of advanced laser anti-attenuation technology to ensure long-term stability of equipment;
·ModBus-RTU standard communication protocol, easy access;
·Standard wire length: 5 meter.
Colorlight SSR-PM Air quality (PM2.5/PM10) Transmitter Detector Parameters：
| Specification | |
| Power supply | AC 100~240V 50/60Hz |
| Power Adapter | DC12V 2A |
| Circuit operating temperature | -20℃~+60℃， ；0%RH~80%RH |
| Communication interface | 485 (modbus) protocol Baud Rate: 2400, 4800 (default), 9600 |
| Parameter settings | Be configured with software provided by the configuration 485 |
| Resolution | 1ug/m3 |
| Accuracy | ±10% |
| Baud rate | 1200 bit/s,2400 bit/s, 4800 bit/s, 9600 bit/s, 19200 bit/s |
| Measuring range | PM2.5：0~6000ug/m3 PM10：0~6000ug/m3 |
| Response speed | ≤90S |
| Warm up time | ≤2min |
