Low cost-high reliability
CASE:812; Size:205×114×50mm
Protections Over load/Short circuit
Low output ripple&noise
Built-in EMI filter
Forced air cooling by Built-in DC fan
1 year warranty

Input frequency--------------------47-63Hz
AC input voltage range---------------176~264VAC/47~63HZ
AC inrush current---------------------Cold start 40A/230VAC
Line regulation（full load）-------------≤0.5%
DC adjustment range------------------±10% rated output voltage
Rise hold up time-------------------50mS 20mS at full load（typical）
Output over load protection----------110%-150% shut off, AC recycle to re-start
Withstand voltage---------------------I/P-O/P,I/P-FG:1.5KVAC, O/P-FG,0.5KVAC,1min
Storage temperature-------------------- -20C~+85C 20%~95%RH(non condensing)
Working temperature------------------10~+40C@ 100% +60C@ 60% load
EMC standards------------------ -----Design refer to GB9254 EN55022 class A
Safety standards-----------------------Design refer to GB4943 UL60950-1,EN60950-1
Cooling method----------------------- Forced air cooling by Built-in DC fan
