Indoor P1.667mm Soft Flexible LED Display Module 240×120 Flexible LED Panel

Indoor P1.667mm Soft Flexible LED Display Module 240×120 Flexible LED Panel

  1. Flexible led display is suitable for shopping malls, bars, stage backgrounds, exhibition halls, planning exhibition halls, etc.
  2.  Soft, thin and light, suitable for any bending effect Flexible,lightweight, easy to install and maintain

P1.667 Soft Flexible LED Display Module 240×120 Flexible LED Panel Main Specifications:

Module Specifications
1 Pixel Pitch 1.667mm
2 Pixel Configuration SMD3in1
3 Module Resolution 144×72 pixels
4 Module Pixles 360000 pixels/module
5 Module Size 240x120mm
Specifications
1 Screen Brightness ≥1000cd/m2
2 Driving Method 1/36 scan
3 Min Viewing Distance1 m
4 Max. Power Consumption 600W/m2
5 Average Power Consumption 200W/m2
6 Gray Level 14bits input, 4096 levels(212)
7 Display Color 16M
8 Frame Frequency ≥60Hz
9 Refresh Frequency ≥1920Hz
10 Uninterrupted Working Hours ≥72 hours
11 Screen Life-span ≥100,000 hours
12 MTBF ≥5,000 hours
13 Discrete Blind Spot Rate <1/10000
14 Continuous Blind Spot Rate None
15 Blind Spot Rate <1/10000
16 Screen Plainness <±1mm
17 Power Supply Mode AC220±10%  50Hz/AC110±10%  60Hz
18 Environment Temperature & Humidity Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH
19 Control Mode Synchronous display with control PC by DVI
20 Control System DVI video card + full color control card + fiber system( optional)
21 Display Content Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
22 Interface Standard Ethernet
23 Transmission Distance Multi mode fiber <500m, single mode fiber <30km,internet cable <100m


Indoor Flexible Soft LED Display Module Specification:

Pixel Pitch LED Type Density（dot/㎡） Module Pixel Module Size（mm） Driving Mode Brightness(Nits)
240*120mm Series soft flexible led display module
1.25mm SMD1010 640000 192*96 240*120mm 1/64Scan 700-900
1.5625mm SMD1212 409600 128*96 200*150mm 1/48Scan 700-900
1.579mm SMD1212 409600 152*76 240*120mm 1/38Scan 700-900
1.667mm SMD1212 360000 144*72 240*120mm 1/36Scan 700-900
1.875mm SMD1212 284444 128*64 240*120mm 1/32Scan 700-900
1.875mm SMD1515 284444 128*64 240*120mm 1/32Scan 700-900
2mm SMD1515 250000 120*60 240*120mm 1/30Scan 700-900
2.5mm SMD1515 160000 96*48 240*120mm 1/24Scan 700-900
3mm SMD2121 111111 80*40 240*120mm 1/20Scan 700-900
4mm SMD2121 62500 60*30 240*120mm 1/15Scan 700-900
320*160mm Series flexible soft led display module
1.86mm SMD1212 288906 172*86 320*160mm 1/43Scan 700-900
2mm SMD1515 250000 160*80 320*160mm 1/40Scan 700-900
2.5mm SMD1515 160000 128*64 320*160mm 1/32Scan 700-900
3.076mm SMD1515 105625 104*52 320*160mm 1/26Scan 700-900
5mm SMD2121 40000 64*32 320*160mm 1/16Scan 700-900
256*128mm Series flexible soft led display panel
2mm SMD1515 250000 128*64 256*128mm 1/32Scan 700-900
4mm SMD2121 62500 64*32 256*128mm 1/16Scan 700-900
$58.50 USD
$58.50 USD
Sale Sold out
Taxes included.

P1.667-ISF36S-SMD1515-144x72
View full details
Product Product subtotal Quantity Price Product subtotal
Indoor P1.667mm Soft Flexible LED Display Module 240×120 Flexible LED Panel
Indoor P1.667mm Soft Flexible LED Display Module 240×120 Flexible LED PanelP1.667-ISF36S-SMD1515-144x72
Indoor P1.667mm Soft Flexible LED Display Module 240×120 Flexible LED PanelP1.667-ISF36S-SMD1515-144x72
$58.50/ea		 $0.00
$58.50/ea $0.00

Description

  1. Flexible led display is suitable for shopping malls, bars, stage backgrounds, exhibition halls, planning exhibition halls, etc.
  2.  Soft, thin and light, suitable for any bending effect Flexible,lightweight, easy to install and maintain

P1.667 Soft Flexible LED Display Module 240×120 Flexible LED Panel Main Specifications:

Module Specifications
1 Pixel Pitch 1.667mm
2 Pixel Configuration SMD3in1
3 Module Resolution 144×72 pixels
4 Module Pixles 360000 pixels/module
5 Module Size 240x120mm
Specifications
1 Screen Brightness ≥1000cd/m2
2 Driving Method 1/36 scan
3 Min Viewing Distance1 m
4 Max. Power Consumption 600W/m2
5 Average Power Consumption 200W/m2
6 Gray Level 14bits input, 4096 levels(212)
7 Display Color 16M
8 Frame Frequency ≥60Hz
9 Refresh Frequency ≥1920Hz
10 Uninterrupted Working Hours ≥72 hours
11 Screen Life-span ≥100,000 hours
12 MTBF ≥5,000 hours
13 Discrete Blind Spot Rate <1/10000
14 Continuous Blind Spot Rate None
15 Blind Spot Rate <1/10000
16 Screen Plainness <±1mm
17 Power Supply Mode AC220±10%  50Hz/AC110±10%  60Hz
18 Environment Temperature & Humidity Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH
19 Control Mode Synchronous display with control PC by DVI
20 Control System DVI video card + full color control card + fiber system( optional)
21 Display Content Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
22 Interface Standard Ethernet
23 Transmission Distance Multi mode fiber <500m, single mode fiber <30km,internet cable <100m


Indoor Flexible Soft LED Display Module Specification:

Pixel Pitch LED Type Density（dot/㎡） Module Pixel Module Size（mm） Driving Mode Brightness(Nits)
240*120mm Series soft flexible led display module
1.25mm SMD1010 640000 192*96 240*120mm 1/64Scan 700-900
1.5625mm SMD1212 409600 128*96 200*150mm 1/48Scan 700-900
1.579mm SMD1212 409600 152*76 240*120mm 1/38Scan 700-900
1.667mm SMD1212 360000 144*72 240*120mm 1/36Scan 700-900
1.875mm SMD1212 284444 128*64 240*120mm 1/32Scan 700-900
1.875mm SMD1515 284444 128*64 240*120mm 1/32Scan 700-900
2mm SMD1515 250000 120*60 240*120mm 1/30Scan 700-900
2.5mm SMD1515 160000 96*48 240*120mm 1/24Scan 700-900
3mm SMD2121 111111 80*40 240*120mm 1/20Scan 700-900
4mm SMD2121 62500 60*30 240*120mm 1/15Scan 700-900
320*160mm Series flexible soft led display module
1.86mm SMD1212 288906 172*86 320*160mm 1/43Scan 700-900
2mm SMD1515 250000 160*80 320*160mm 1/40Scan 700-900
2.5mm SMD1515 160000 128*64 320*160mm 1/32Scan 700-900
3.076mm SMD1515 105625 104*52 320*160mm 1/26Scan 700-900
5mm SMD2121 40000 64*32 320*160mm 1/16Scan 700-900
256*128mm Series flexible soft led display panel
2mm SMD1515 250000 128*64 256*128mm 1/32Scan 700-900
4mm SMD2121 62500 64*32 256*128mm 1/16Scan 700-900
