Description
The LINSN TS952 LED Display Sender Box includes one DVI input and one HDMI input, both compatible with 4K video source inputs. It features a readback capability for RCG configuration files from the receiving card and supports broadcasting of receiving card configuration files (.RCG).
1) 1 DVI input;
2) 1 HDMI input;
3) Support 4K video sources input;
4) Readback function of RCG configuration file from receiving card;
5) Support receiving card configuration file (.RCG) broadcasting function;
6) Support display connection file(.CON) broadcasting function;
7) Support video input of 12bit/10bit/8bit;
8) Support 16bit gray grade;
9) 1 audio input;
10) 4 RJ45 output ports, supports video sources with resolution, 2560x1024, 1920x1200, 2048x1152,etc.
11) Video formats supported: RGB,YCrCB4:2:2,YCrCb4:4:4;
12) Support man-machine interaction through LCD
13) LED screen brightness adjustable directly through knob;
14) No PC required for LED screen configuration;
15) Cascading supported;
16) 1 light sensor interface, for automatic brightness adjustment.
Specifications Download
